Sand Washing Machine
XSD series wheel sand washing machine is a high-efficiency and energy-saving sand washing machine developed on the basis of traditional wheel sand washing machine for wet sand making process.
It can be equipped with an impact crusher to remove mud powder and impurities from the screened machine-made sand to improve the quality of the machine-made sand.
Feeding size: <10mm
Capacity: 20-180t/h
Brief Introduction
The wheel sand washing machine is an artificial (including natural sand) wheel bucket washing equipment, which can clean and separate the stone powder and soil in the sand and gravel, thereby improving the quality of the sand. It has the characteristics of water saving, energy saving, dust removal and impurity removal.
Scope and Application
It is mainly used in construction sites, sand and gravel plants, glass factories, hydropower stations and other industries. It is also used for washing, grading and dehydration in the production of 70 sand, quartz sand, oil well backfill pressure sand and other sand and gravel.
gravel
quartz
construction
sand
hydropower
Advantages of Sand Washing Machine
Wheel bucket structure, simple and efficient work.
Motor reducer drive, traditional, stable and reliable.
High sand washing efficiency, large processing capacity and low power consumption.
The transmission system is isolated from water and easy to maintain.
Specifications and performance parameters
Model | XSD2610 | XSD3016 | XSD3620 |
Wheel Diameter and Width (mm) | Φ2600*1000 | Φ3000*1600 | Φ3600*2000 |
Input Size (mm) | ≤10 | ≤10 | ≤10 |
Capacity (t/h) | 20-50 | 50-120 | 120-180 |
Power (Kw) | 7.5 | 15 | 18.5 |
Weight (ton) | 2.68 | 3.26 | 4.3 |
Dimension (mm) | 3320*2125*2670 | 3810*2686*3085 | 4500*3206*3480 |
